Advantech IPC-610BP-30LD

IPC-610BP-00LD w/PS8-300ATX-ZBE(62368)

  • Supports an ATX motherboard or a backplane with up to 15 slots.
  • Shock-resistant disk drive bay design holds up to three 5.25" and one 3.5" disk drives.
  • Special hold-down clamp design with rubber cushions protects the cards from shocks and vibrations.
  • Power and HDD activity notification improves system availability.
  • Front-accessible air filter for easy system maintenance.
  • Lockable front door prevents unauthorized access.
  • Flexible mechanical design supports both 300 W single PS/2 and redundant ATX power supply.

Terms and Conditions

4U 15-Slot Rackmount Chassis with Front-Accessible Fan
Form FactorForm Factor4U Rackmount
Disk Drive Bay3.5 External Bay1
Drive Bay5.25 External Bay3
CoolingFan1(12cm / 82CFM)
Air FilterYes
MiscellaneousLED IndicatorsPower status and HDD activity
ControlPower switch and system reset button
EnvironmentOperating-Temperature0 ~ 40° C (32 ~ 104° F) (Operational humidity: 40° C @ 85% RH Non-Condensing)
Non-Operational Temperature-20 ~ 60° C (-4 ~ 140° F) and 40° C @ 95% RH Non-Condensing
Operating Vibration1 Grms
Non-Operating Vibration2 G
Physical CharacteristicsDimensions (W x H x D)482 x 177 x 479 mm (19'' x 7'' x 18.9'')
Weight14.5 kg ( 31.9 lb )
Power SupplyPower Supply300W (Single)
