* Images are for reference only. See product specifications (datasheet).
Technical Documentation:
insert_drive_file MIC-743-AT_DS(122325)20251229100750.pdf
Terms and Conditions
| Processor System | CPU | 14 core Arm® Neoverse V3AE (64-bit) SMP CPU architecture L1 Cache (I, D) per core: 64KB + 64KB, L2 1MB, L3 16MB |
| GPU | 2560 NVIDIA® CUDA® cores 96 5th Gen Tensor cores MAXN: 1.57 GHz | |
| Memory | 128GB LPDDR5X | |
| Ethernet | RJ45 | 1 x 10/100/1000/2500/5000 Mbps Ethernet |
| QSFP28 | 4 x 25GbE | |
| I/O | Display | HDMI (Max. resolution 3840x2160 @ 60Hz) |
| USB | 4 x USB 3.2 Gen 2 | |
| OTG USB | 1 x Micro USB | |
| Console | 1 x microUSB console for debug (UART to USB) | |
| Audio | 1 x audio speaker out, MIC in on board | |
| SIM card | 1 x Nano SIM on side of board | |
| Expansion | M.2 Ekey | 1 x 2230 E-key (Signal: PCIex1 + USB2.0) |
| M.2 Bkey | 1 x 3052/3042 B-key (Signal: USB3.0 + USB2.0) | |
| Power | Input | 19-36V |
| Power Type | Terminal Block 2 Pin | |
| Internal pin header | 3 x SMART FAN | |
| Environment | Operating Temperature | -10 ~ 35 °C with 0.7 m/s air flow |
| Operating Humidity | 95% @ 40 °C (non-condensing) | |
| Vibration | 3 Grms @ 5 ~ 500 Hz, random, 1 hr/axis | |
| Mechanical | Dimension (W x H x D) | 195 x 200 x 71.5 mm with rubber foot |
| Weight | 2kg | |
| Installation | Desktop | |
| Operating System | JetPack | NVIDIA JetPack 7.0 |
| Certification | EMC, Safety | CB/UL/CE/FCC/BSMI/CCC (No RED certification) |
Data sheet
