* Images are for reference only. See product specifications (datasheet).
Technical Documentation:
insert_drive_file ASMB-977S_DS(071725)20250718174210.pdf
Terms and Conditions
| Processor System | CPU | 5th/4th Gen Intel® Xeon® Scalable processors |
| Socket Q'ty | 2 x LGA4710 | |
| TDP | Up to 350 W | |
| Chipset | Intel® C741 | |
| Memory | Type and Speed | DDR5 5200 MHz RDIMM |
| Channel | 16 | |
| System Max Capacity | 4 TB | |
| Expansion | PCIe/PCI Module | 6 x PCIe 5.0 x16 |
| Internal Storage | M.2 | 2 (PCIe 3.0 x4, SATA) |
| Rear I/O | Display | 1 x VGA port |
| USB | 2 x USB 3.2 Gen1 | |
| LAN | Controller | Intel® I210, Intel® X710 |
| 1GbE | 2 | |
| 10GbE | 2 | |
| Security | TPM | TPM 2.0 onboard |
| Storage | SATA Port | 4 x (via Mini-SAS HD SFF-8643), 1 x SATA3 |
| Cooling | System Fan | 5 x system, 2 x CPU, 2 x 8-pin external fans |
| System Management | Controller | Aspeed AST2600 |
| IPMI | Advantech remote monitoring utility | |
| Watchdog Timer | Output | System Reset |
| Environment | Operating-Temperature | 0 ~ 40 °C |
| Non-Operating Temperature | -40 ~ 85 °C | |
| Operating Humidity | 10 ~ 95% | |
| Non-Operating Humidity | 10 ~ 95%, non-condensing | |
| Physical Characteristics | Form Factor | EATX |
| Dimensions (L x H) | 380 x 349.5 mm (15" x 13.8") | |
| Certification | EMC | CE/FCC |
