* Images are for reference only. See product specifications (datasheet).
Technical Documentation:
insert_drive_file UTC-115G_DS(122123)20231221135310.pdf
Terms and Conditions
| Color | Color | Silver |
| Display | Size | 15.6" TFT LCD |
| Max. Resolution | FHD (1920 x 1080) | |
| Brightness | 300 cd/m² | |
| Touch Screen | Type | Projected Capacitive |
| Processor System | CPU | Intel® Pentium® N4200 |
| Process System | Base/Burst Frequency | 1.10Ghz/2.50Ghz (Quad-Core) |
| Processor System | RAM | 4GB DDR3L |
| Storage | 128G SSD | |
| OS | Windows 10 IoT Enterprise 64bit | |
| Process System | Stereo Speaker | 2 x 2W |
| Dimension (WxHxD) | 398.8 x 248.2 x 29.5 | |
| Weight | 2.4 Kg | |
| I/O Interface | Serial Port | 2 x COM (RS-232) |
| USB Port | 4 x USB 3.0 / 2 x USB 3.0 (optional) | |
| Output | 1 x HDMI | |
| Audio | 1 x Audio Phone Jack | |
| Ethernet | 2 x Gigabit Ethernet (RJ-45) | |
| Speaker | 2 x 2W Speaker | |
| Extendable Slot | 1 x M.2 key2230, 1 x M.2 key2242 | |
| Peripheral | WLAN | IEEE 802.11a/b/g/n/ac |
| Bluetooth | Bluetooth® v4.1 | |
| Environment | Operating Temperature | 0 ~ 40 °C |
| Operating Humidity | 10 ~ 95% @ 40°C non-condensing | |
| Vibration | 0.5G | |
| Shock | 10G peak acceleration (11 msec. duration) | |
| System Protection | IP65 front panel | |
| Power | Input Rating | 12 V/5 A~24 V/2.5 A (60W ITE Adapter) |
| PoE | IEEE 802.3at/30W (Optional) | |
| Power Supply | Power consumption | 26W |
