* Images are for reference only. See product specifications (datasheet).
Technical Documentation:
insert_drive_file UTC-315DGK_DS(082624)20240827152510.pdf
Terms and Conditions
| Color | Color | Black |
| Display | Size | 15.6" TFT LCD |
| Max. Resolution | HD (1366 x 768) ; Optional FHD (1920 x 1080) | |
| Brightness | 220 cd/m² | |
| Touch Screen | Type | Analog Resistive 5-wire |
| Processor System | CPU | Intel® Celeron® J1900 |
| OS Support | OS Support | Win 10 IoT Enterprise 64bit/ Linux/ Android 6.0 |
| Processor System | RAM | 4GB DDR3L |
| Storage | 1 x 2.5 internal SATA HDD bay | |
| I/O Interface | Serial Port | 1 x COM (RS-232) ; 1 x COM (RS-232/422/485) |
| USB Port | 5 x USB 2.0, 1 x USB 3.0 | |
| Ethernet | 2 x Gigabit Ethernet (RJ-45) | |
| Output | 1 x HDMI | |
| Cash Drawer | 1 x RJ11 | |
| Audio | 1 x Line-out, 1 x Mic-in | |
| Speaker | 2 x 1W Speaker | |
| Extendable Slot | Full-size MiniPCIe/mSATA | |
| Environment | Operating Temperature | 0~40° C |
| Operating Humidity | 10 ~ 95% @ 40°C non-condensing | |
| System Protection | IP65 front panel | |
| Vibration | 0.5G | |
| Shock | 10G peak acceleration (11 msec. duration) | |
| Power | Input Rating | 12 V/7 A (84W ITE Adapter) *Optional 12-30V |
