* Images are for reference only. See product specifications (datasheet).
Technical Documentation:
insert_drive_file AFE-R761_DS(100725)20251007101445.pdf
Terms and Conditions
| Form Factor | Form Factor | Box PC |
| Processor | CPU | Rockchip RK3588 Arm Quad Cortex-A76 2.4 GHz and Quad Cortex-A55 1.8 GHz |
| NPU | Up to 6 Tops. Supports: TensorFlow, Caffe, Tflite, Pytorch, Onnx NN, Android NN, etc. | |
| Memory | Technology | LPDDR4 4224MT/s |
| Capacity | Onboard 8 GB, Max. capacity 32 GB | |
| Flash | 64 GB eMMC NAND Flash for OS and boot loader | |
| Display | Graphic Engine | Arm Mali-G610 MP4 GPU, high-performance OpenGL ES 1.1, 2.0 and 3.2, OpenCL 2.2, Vulkan 1.2, etc. |
| H/W Video Codec | Decoder: H.265/VP9 8K @ 60 fps, H.264 8K @ 30 fps, H.263 ,VC-1, VP8, MVC, AV1, MPEG-4/2/1 | |
| HDMI / DisplayPort* | 1 x HDMI 2.0, up to 3821 x 2160 @30Hz | |
| Ethernet | Chipset | 2 x RTL8211FSI, 1 x RTL8119I, 1 x Intel I226 |
| Speed | 1 x 2.5Gbps, 3 x 10/100/1000 Mbps | |
| Watchdog Timer | WatchDog Timer | 1~6553s, default 60s, power on/off 1s |
| Front I/O Interface | USB | 1 x USB3.0 by 1 TypeA, 1 x USB3.0 by 1 TypeA/OTG |
| Audio | 1 x Line out/Mic in | |
| RJ-45 | 4 | |
| HDMI | 1 | |
| Power Button | 1 | |
| Side I/O Interface | COM | 2 x RS-232/485 (Default RS-232, s/w configured) |
| CAN Bus | 2 x CAN FD (5M) | |
| Rear I/O Interface | SD Socket | 1 x Micro SD Slot |
| Button | 1 x Reset, 1 x Maskrom, 1 x Recovery | |
| Expansion | SIM Socket | 1x SIM slot |
| M.2 | 2x, 1x M.2 2230 E key and 1x M.2 3052 B key | |
| B2B Connector | 2 x MIPI-CSI 4 Lane, 1 x USB2.0, 1xUART, 1x I2C, 1 x SPI, through 120-pin B2B connector | |
| Power | Power Supply Voltage | 12 VDC ~ 24 VDC |
| Connector | 2-pin phoenix head | |
| Power Consumption | Typical(Idle mode) 5.65W@12V, Max.(Full loading) 11.68W@12V | |
| Environment | Operational Temperature | 0~60°C |
| Humidity | 40° C @ 95% RH Non-Condensing | |
| Mechanical | Dimensions (L x W x H) | 175 x 120 x 56.7 mm |
| Operating System | Linux | Linux Debian12 and Android14 |
| Certification | EMC | CE / FCC / CCC / Class B |
