Advantech USM-110A-WR120

Name: Advantech USM-110A-WR120
Brand: Advantech
SKU: USM-110A-WR120
Price: 366 EUR
Availability: OutOfStock

€366

Tax excluded

Cortex A17,2G/16G,2XHDMI,Android6.0,IMM

Built-in Arm® Cortex®-A17 quad-core processor (1.6 GHz).
2 GB onboard memory.
16GB eMMC onboard expandable MicroSD (TF) storage.
Dual HDMI outputs (1 x supports 4K resolution and 1 x supports 1080P resolution).
Ultra-compact design for easy installation in confined spaces.
Supports various mount options including VESA, wall, pole, Magnet, and DIN-rail mounting.
Can be integrated with optional Wi-Fi, Bluetooth, and 4G LTE modules.
Equipped with WISE-Paas/SignageCMS software, which supports multi-screen displays.
Supports Android 6.0.

Quantity

On enquiry

Terms and Conditions

* Advantech product versions are identified by the last two characters in the product name, with later letters indicating newer versions (e.g., AE, BE, CE, etc.). To see other versions of this product, please click here: Advantech USM-110A-WR120

USM-110W is an ITE-certified edge solution-ready platform (SRP) aimed at diverse clinical applications. Powered by an ARM® Cortex™-A17 quad-core processor with over 5 years longevity support and featuring a dual HDMI interface (supports up to 4K resolution) for video recording and analysis and gateway to collect datas. USM-110W provides a cost-effective, scalable solution for edge-to-hospital information system (HIS) and Internet of things (IoT) applications.

System	CPU	Arm® Cortex®-A17 quad-core processor (1.6 GHz)
Graphics	GPU	Mali-T764
	Graphics Engine	OpenGL ES 1.1/2.0/3.0, OpenCL 1.1, DirectX 11
Memory	Capacity	2 GB onboard DDR3L (1333 MHz )
Storage	Flash	16 GB of onboard eMMC
	Extension	Micro SD
Multimedia	H/W Video Codec	Decoder: 4K 10-bits 60fps H.265, H.264, MPEG-1, MPEG-2, MPEG-4,VC-1, VP8, AVS, MVC/Encoder:1080P for H.264 (BP@level4.0, MP, HP@level4.0), MVC and VP8
	Display Resolution	HDMI1: Native 4K resolution up to 3840 x 2160 (default 1080p)/HDMI2: 1920 x 1080
IO	HDMI	2
	LAN	1 x 10/100/1000 Mbps
	Serial Port	1 (RS232/485/422 by jumper)
	USB 2.0	4
	OTG USB	1
	Audio	1
	Reset	1
	LED Indicators	1 x Power, 1 x Wireless
	DC In	1
Expansion	Micro SD Card Slot	1
	M.2	1 (for Wi-Fi module option)
	Mini-PCIe	1 (for 4G module option)
Mechanical	Dimensions (W x H x D)	156 x 112 x 28 mm (6.14 x 4.41 x 1.10 in)
	Weight	0.43 kg (0.94 lb)
	Power	12V/3A
Installation	Mount Options	VESA (75 x 75), wall, desktop, pole, magnet,DIN rail
Software	Operating System	Android 6.0
	Software	WISE-Paas/SignageCMS
	Display Orientation	Portrait and landscape modes supported
	Client Status Reports	Generates Heartbeat, System reports
	Supported Media Formats	Image: JPG, PNG, BMP, GIF; Video: H.264, MPEG-4, MPEG-2; Text: text, scrolling text; Audio: MP3, AAC,
Environment	Operating Temperature	0 ~ 40° C (32 ~ 104° F)
	Storage Temperature	-40 ~ 85° C (-40 ~ 185° F)
	Relative Humidity	90% @ 40° C (non-condensing)
Certification		CCC/BSMI/CE/FCC/UL/CB

Brand Advantech

Reference USM-110A-WR120

Download

USM-110W_DS(090921)20210909182811.pdf
