* Images are for reference only. See product specifications (datasheet).
Technical Documentation:
insert_drive_file ULI-414_417-Series_DS-(19Jun2024)20240711224639.pdf
Terms and Conditions
| General | Technology | USB |
| Power | Power Input (DC) | 10 ~ 30 VDC |
| Environment | Operating Temperature | -40 ~ 80°C |
| General | Mounting | DIN, Panel |
| Power | 10-30VDC | |
| Temperature | -40 to 80C | |
| Isolation | 4kV | |
| Certification | Safety | CE, FCC, UL/cUL 60950-1, Class I, Division 2 |
| General | USB Port Count | 1 |
| Protection | Isolation | 4,000 VDC |
| ESD Protection | 8 kV (Contact) ; 15 kV (Air) | |
| Upstream USB Port | Standard | USB 2.0 |
| Maximum Transfer Rate | Full-Speed (12 Mbps) | |
| Connector Type | Type B (Female) High Retention | |
| Ports Number | 1 | |
| Downstream USB Port | Standard | USB 2.0 |
| Maximum Transfer Rate | Full-Speed (12 Mbps) | |
| Connector Type | Type A (Female) High Retention | |
| Ports Number | 4 | |
| Supply Current | 500mA for each downstream port | |
| Mechanism | Enclosure (Metal) | Metal |
| Accessory General | Mounting | DIN |
